| MODEL | FREE AIR DELIVERY m³/min. |
MOTOR POWER | OUTLET | SOUND LEVEL | DIMENSIONS | WEIGHT | ||
| 7,5 Bar | 8 Bar | 10 Bar | kW/HP | inch | dB(A) | L x W x H (mm) | (Kg) | |
| HAWK 7.5 D | 1,2 | 1,1 | - | 7.5/10 | 3/4'' | 65 | 1000 X 700 X 830 | 210 |
| HAWK 11 D | 1,80 | 1,7 | - | 11/15 | 3/4'' | 65 | 1050 X 750 X 1000 | 400 |
| HAWK 15 D | 2,8 | 2,6 | 2,1 | 15/20 | 1" | 68 | 1050 X 750 X 1000 | 400 |
| HAWK 22 D | 3,8 | 3,6 | 3,4 | 22/30 | 1 1/4'' | 68 | 1380 X 850 X 1160 | 520 |
| HAWK 37 D | 6,8 | 6,2 | 5,6 | 37/50 | 1 1/2'' | 68 | 1500 X 1000 X 1330 | 750 |
| HAWK 45 D | 7,4 | 7,0 | 6,2 | 45/60 | 2'' | 68 | 1500 X 1000 X 1330 | 780 |
| HAWK 55 D | 10,8 | 10,2 | 9,0 | 55/75 | 2'' | 72 | 1900 X 1250 X 1600 | 1,270 |
| HAWK 75 D | 13,5 | 12,6 | 11,2 | 75/100 | 2'' | 72 | 2000 X 1250 X 1670 | 1,300 |
| HAWK 90 D | 16,5 | 15,0 | 13,8 | 90/125 | 2'' | 72 | 2000 X 1250 X 1670 | 1,520 |
| HAWK 110 D | 21,0 | 19,8 | 17,4 | 110/150 | 2'' | 75 | 2700 X 1600 X 1842 | 2,100 |
| HAWK 132 D | 24,1 | 23,5 | 20,8 | 132/180 | 2'' | 75 | 2700 X 1600 X 1842 | 2,150 |
| HAWK 160 D | 28,7 | 27,6 | 24,9 | 160/200 | 3" | 75 | 2700 X 1600 X 1842 | 2450 |
| HAWK 185 D | 32,0 | 30,5 | 27,5 | 185/250 | 3" | 75 | 3650 X 1980 X 2152 | 2,520 |
| HAWK 200 D | 36,7 | 34,5 | 30,2 | 200/270 | 3" | 75 | 3650 X 1980 X 2152 | 3,750 |
| HAWK 250 D | 43,0 | 41,0 | 37,8 | 250/340 | 3" | 75 | 3650 X 1980 X 2152 | 4,250 |
